PowerShell DSC: Desired State Configuration for Windows Server

PowerShell DSC: Desired State Configuration for Windows Server

Introduction

[Explain infrastructure-as-code benefits; DSC enforces desired state continuously, preventing configuration drift.]

Prerequisites

• Windows Server 2019+
• PowerShell 5.1 or PowerShell 7+
• Administrative access

DSC Architecture

Core Concepts

Step-by-Step Guide

Step 1: Simple Configuration

Configuration WebServerConfig
{
    Node "WebServer01"
    {
        WindowsFeature IIS
        {
            Ensure = "Present"
            Name = "Web-Server"
        }

        WindowsFeature ASP
        {
            Ensure = "Present"
            Name = "Web-Asp-Net45"
            DependsOn = "[WindowsFeature]IIS"
        }

        File WebContent
        {
            Ensure = "Present"
            DestinationPath = "C:\inetpub\wwwroot\index.html"
            Contents = "<h1>Hello from DSC</h1>"
            Type = "File"
            DependsOn = "[WindowsFeature]IIS"
        }
    }
}

Step 2: Compile Configuration

# Generate MOF file
WebServerConfig -OutputPath C:\DSC\Configs

# Apply configuration
Start-DscConfiguration -Path C:\DSC\Configs -Wait -Verbose -Force

Step 3: Configure LCM

[DSCLocalConfigurationManager()]
Configuration LCMConfig
{
    Node "WebServer01"
    {
        Settings
        {
            RefreshMode = 'Push'
            ConfigurationMode = 'ApplyAndAutoCorrect'
            RebootNodeIfNeeded = $true
            RefreshFrequencyMins = 30
        }
    }
}

LCMConfig -OutputPath C:\DSC\LCM
Set-DscLocalConfigurationManager -Path C:\DSC\LCM -Verbose

Step 4: Using Configuration Data

$ConfigData = @{
    AllNodes = @(
        @{
            NodeName = "WebServer01"
            Role = "WebServer"
        }
        @{
            NodeName = "DBServer01"
            Role = "DatabaseServer"
        }
    )
}

Configuration MultiNodeConfig
{
    Node $AllNodes.Where{$_.Role -eq "WebServer"}.NodeName
    {
        WindowsFeature IIS
        {
            Ensure = "Present"
            Name = "Web-Server"
        }
    }

    Node $AllNodes.Where{$_.Role -eq "DatabaseServer"}.NodeName
    {
        WindowsFeature SQLServer
        {
            Ensure = "Present"
            Name = "SQL-Server-Full"
        }
    }
}

MultiNodeConfig -ConfigurationData $ConfigData -OutputPath C:\DSC\Configs

Step 5: Custom DSC Resources

# Install from PowerShell Gallery
Install-Module -Name xWebAdministration -Force

Configuration AdvancedIIS
{
    Import-DscResource -ModuleName xWebAdministration

    Node "WebServer01"
    {
        xWebAppPool AppPool
        {
            Name = "MyAppPool"
            Ensure = "Present"
            managedRuntimeVersion = "v4.0"
        }

        xWebsite Website
        {
            Name = "MyWebsite"
            State = "Started"
            PhysicalPath = "C:\inetpub\mysite"
            ApplicationPool = "MyAppPool"
            BindingInfo = @(
                MSFT_xWebBindingInformation {
                    Protocol = "HTTP"
                    Port = 8080
                }
            )
            DependsOn = "[xWebAppPool]AppPool"
        }
    }
}

Step 6: Pull Server Setup (Azure Automation)

[DSCLocalConfigurationManager()]
Configuration PullClientConfig
{
    Node "WebServer01"
    {
        Settings
        {
            RefreshMode = 'Pull'
            ConfigurationMode = 'ApplyAndAutoCorrect'
            RebootNodeIfNeeded = $true
        }

        ConfigurationRepositoryWeb AzureAutomation
        {
            ServerURL = 'https://<region>.agentsvc.azure-automation.net/accounts/<guid>'
            RegistrationKey = '<registration-key>'
            ConfigurationNames = @('WebServerConfig')
        }
    }
}

Step 7: Compliance Checking

# Test configuration compliance
Test-DscConfiguration -Verbose

# Get current configuration status
Get-DscConfiguration

# Get LCM state
Get-DscLocalConfigurationManager

Advanced Scenarios

Partial Configurations

[DSCLocalConfigurationManager()]
Configuration PartialConfig
{
    Node "WebServer01"
    {
        Settings
        {
            RefreshMode = 'Pull'
            ConfigurationMode = 'ApplyAndAutoCorrect'
        }

        PartialConfiguration BaseOS
        {
            Description = 'Base OS Configuration'
            ConfigurationSource = '[ConfigurationRepositoryWeb]AzureAutomation'
        }

        PartialConfiguration AppConfig
        {
            Description = 'Application Configuration'
            ConfigurationSource = '[ConfigurationRepositoryWeb]AzureAutomation'
            DependsOn = '[PartialConfiguration]BaseOS'
        }
    }
}

Composite Resources

Configuration WebServerComposite
{
    Import-DscResource -ModuleName PSDesiredStateConfiguration

    WindowsFeature IIS
    {
        Ensure = "Present"
        Name = "Web-Server"
    }

    WindowsFeature ASPNET
    {
        Ensure = "Present"
        Name = "Web-Asp-Net45"
        DependsOn = "[WindowsFeature]IIS"
    }
}

Monitoring & Reporting

# Get DSC events
Get-WinEvent -LogName "Microsoft-Windows-Dsc/Operational" | Select-Object -First 10

# Custom compliance report
$nodes = @("WebServer01", "WebServer02")
foreach ($node in $nodes) {
    $result = Test-DscConfiguration -ComputerName $node
    [PSCustomObject]@{
        Node = $node
        InDesiredState = $result.InDesiredState
        Timestamp = Get-Date
    }
}

Integration with Azure Automation

1. Import configurations to Azure Automation account
2. Compile configurations in Azure
3. Onboard VMs to Azure Automation DSC
4. Monitor compliance via portal

Troubleshooting

Issue: Configuration not applying
Solution: Check LCM mode; verify MOF syntax; review DSC event logs

Issue: Resource dependency loop
Solution: Review DependsOn chains; ensure no circular references

Issue: Credential handling errors
Solution: Use PSDscAllowPlainTextPassword or certificate encryption

Best Practices

• Use configuration data for environment-specific values
• Leverage composite resources for reusability
• Implement pull mode for scale and centralized management
• Monitor drift detection with scheduled compliance checks
• Version control DSC configurations in Git

Key Takeaways

• DSC enforces desired state declaratively.
• LCM monitors and auto-corrects drift.
• Pull mode centralizes configuration management.
• Azure Automation DSC simplifies enterprise deployment.

Next Steps

• Migrate manual server configs to DSC
• Set up Azure Automation DSC pull server
• Build custom DSC resources for org-specific needs

Additional Resources

• PowerShell DSC Overview
• Azure Automation State Configuration
• DSC Resources

Which server configuration will you automate first?
