Enterprise DevSecOps Platform: GitHub Advanced Security + Azure DevOps + Container Security

Introduction: Security Shifts Left, Right, and Everywhere

DevSecOps is not about adding security gates to your pipeline — it's about embedding security into every phase of the software development lifecycle. This deep dive builds a complete DevSecOps platform that catches vulnerabilities in code (SAST), dependencies (SCA), containers (image scanning), infrastructure (IaC scanning), runtime (DAST), and supply chain (SBOM + provenance). Security findings are automatically triaged, tracked, and fed back to developers where they work.

Prerequisites

• GitHub Enterprise Cloud with Advanced Security licenses
• Azure DevOps organization with pipeline agents
• Azure Container Registry with Defender for Containers
• Microsoft Defender for Cloud (CSPM plan)
• Azure Key Vault for secrets management
• Familiarity with YAML pipelines, Docker, and Kubernetes

Phase 1: GitHub Advanced Security Configuration

Code Scanning with CodeQL

# .github/workflows/codeql-analysis.yml
name: "CodeQL Security Analysis"
on:
  push:
    branches: [main, develop]
  pull_request:
    branches: [main]
  schedule:
    - cron: '0 6 * * 1'  # Weekly Monday 6 AM

permissions:
  security-events: write
  contents: read
  actions: read

jobs:
  analyze:
    name: Analyze (${{ matrix.language }})
    runs-on: ubuntu-latest
    strategy:
      fail-fast: false
      matrix:
        language: ['csharp', 'javascript', 'python']
        include:
          - language: csharp
            build-mode: manual
          - language: javascript
            build-mode: none
          - language: python
            build-mode: none

    steps:
      - uses: actions/checkout@v4

      - name: Initialize CodeQL
        uses: github/codeql-action/init@v3
        with:
          languages: ${{ matrix.language }}
          queries: security-extended,security-and-quality
          config: |
            paths-ignore:
              - '**/test/**'
              - '**/tests/**'
              - '**/*.test.*'
            query-filters:
              - exclude:
                  tags: /test/

      - name: Build (.NET)
        if: matrix.language == 'csharp'
        run: dotnet build --configuration Release

      - name: Perform CodeQL Analysis
        uses: github/codeql-action/analyze@v3
        with:
          category: "/language:${{ matrix.language }}"
          upload: true

  dependency-review:
    name: Dependency Review
    runs-on: ubuntu-latest
    if: github.event_name == 'pull_request'
    steps:
      - uses: actions/checkout@v4
      - name: Dependency Review
        uses: actions/dependency-review-action@v4
        with:
          fail-on-severity: high
          deny-licenses: GPL-3.0, AGPL-3.0
          allow-ghsas: GHSA-xxxx-xxxx-xxxx  # Known accepted risks
          comment-summary-in-pr: always

Secret Scanning with Custom Patterns

# .github/secret-scanning/custom-patterns.yml
patterns:
  - name: "Internal API Key"
    pattern: "CORP-API-[A-Z0-9]{32}"
    description: "Corporate internal API key format"
    severity: "critical"

  - name: "Database Connection String"
    pattern: "Server=(?:tcp:)?[a-zA-Z0-9.-]+;.*Password=[^;\"']+"
    description: "SQL Server connection string with embedded password"
    severity: "critical"

  - name: "Azure Storage Account Key"
    pattern: "[A-Za-z0-9+/]{86}=="
    description: "Potential Azure Storage account key (Base64, 88 chars)"
    severity: "high"
    additional_match_requirements:
      - context_contains: ["AccountKey", "StorageAccountKey", "AZURE_STORAGE"]

  - name: "Internal Certificate Passphrase"
    pattern: "CERT-PASS-[A-Za-z0-9!@#$%]{16,}"
    description: "Internal certificate passphrase format"
    severity: "critical"

Phase 2: Azure DevOps CI/CD Security Pipeline

Comprehensive Security Pipeline

# azure-pipelines/security-pipeline.yml
trigger:
  branches:
    include: [main, develop, release/*]

pool:
  vmImage: 'ubuntu-latest'

variables:
  - group: 'security-scanning-config'
  - name: acrName
    value: 'corpcontainerregistry'
  - name: imageRepository
    value: 'app/order-service'

stages:
  - stage: SecurityScan
    displayName: 'Security Scanning'
    jobs:
      - job: SAST
        displayName: 'Static Application Security Testing'
        steps:
          - task: UseDotNet@2
            inputs:
              version: '8.x'

          - script: |
              dotnet tool install --global security-scan
              dotnet tool install --global dotnet-retire
            displayName: 'Install security tools'

          - script: |
              dotnet restore
              dotnet build --no-restore
            displayName: 'Build application'

          - task: SonarCloudPrepare@2
            inputs:
              SonarCloud: 'sonarcloud-connection'
              organization: 'contoso'
              scannerMode: 'MSBuild'
              projectKey: 'contoso_order-service'
              extraProperties: |
                sonar.cs.opencover.reportsPaths=$(Build.SourcesDirectory)/coverage.xml
                sonar.exclusions=**/Migrations/**,**/Tests/**

          - task: SonarCloudAnalyze@2
            displayName: 'Run SonarCloud Analysis'

          - task: SonarCloudPublish@2
            inputs:
              pollingTimeoutSec: '300'

      - job: SCA
        displayName: 'Software Composition Analysis'
        steps:
          - script: |
              # Check for known vulnerabilities in NuGet packages
              dotnet list package --vulnerable --include-transitive --format json > vulnerable-packages.json

              # Parse and fail on critical/high vulnerabilities
              CRITICAL=$(jq '[.projects[].frameworks[].topLevelPackages[]? | select(.vulnerabilities[]?.severity == "Critical")] | length' vulnerable-packages.json)
              HIGH=$(jq '[.projects[].frameworks[].topLevelPackages[]? | select(.vulnerabilities[]?.severity == "High")] | length' vulnerable-packages.json)

              echo "Critical vulnerabilities: $CRITICAL"
              echo "High vulnerabilities: $HIGH"

              if [ "$CRITICAL" -gt 0 ]; then
                echo "##vso[task.logissue type=error]Critical vulnerabilities found in dependencies"
                exit 1
              fi
            displayName: 'Check NuGet vulnerabilities'

          - script: |
              # Generate SBOM
              dotnet tool install --global Microsoft.Sbom.DotNetTool
              sbom-tool generate \
                -b $(Build.BinariesDirectory) \
                -bc $(Build.SourcesDirectory) \
                -pn "OrderService" \
                -pv $(Build.BuildNumber) \
                -ps "Contoso" \
                -nsb "https://contoso.com/sbom" \
                -V Verbose
            displayName: 'Generate SBOM (SPDX)'

          - publish: $(Build.BinariesDirectory)/_manifest
            artifact: 'SBOM'
            displayName: 'Publish SBOM artifact'

      - job: IaCScan
        displayName: 'Infrastructure-as-Code Scanning'
        steps:
          - script: |
              pip install checkov
              checkov -d infra/ \
                --framework bicep arm_template dockerfile \
                --output junitxml \
                --output-file-path checkov-results.xml \
                --soft-fail-on LOW \
                --hard-fail-on CRITICAL,HIGH \
                --skip-check CKV_AZURE_35,CKV_AZURE_43
            displayName: 'Run Checkov IaC scan'

          - task: PublishTestResults@2
            inputs:
              testResultsFormat: 'JUnit'
              testResultsFiles: 'checkov-results.xml'
              testRunTitle: 'IaC Security Scan'
            condition: always()

  - stage: ContainerSecurity
    displayName: 'Container Security'
    dependsOn: SecurityScan
    jobs:
      - job: BuildAndScan
        displayName: 'Build and Scan Container Image'
        steps:
          - task: Docker@2
            displayName: 'Build container image'
            inputs:
              containerRegistry: 'acr-connection'
              repository: $(imageRepository)
              command: 'build'
              Dockerfile: '**/Dockerfile'
              tags: |
                $(Build.BuildId)
                latest

          - script: |
              # Install and run Trivy for container scanning
              curl -sfL https://raw.githubusercontent.com/aquasecurity/trivy/main/contrib/install.sh | sh -s -- -b /usr/local/bin

              trivy image \
                --severity CRITICAL,HIGH \
                --exit-code 1 \
                --format json \
                --output trivy-results.json \
                --ignore-unfixed \
                $(acrName).azurecr.io/$(imageRepository):$(Build.BuildId)

              # Also generate SARIF for GitHub Advanced Security integration
              trivy image \
                --format sarif \
                --output trivy-results.sarif \
                $(acrName).azurecr.io/$(imageRepository):$(Build.BuildId)
            displayName: 'Trivy container scan'

          - script: |
              # Sign container image with Notation (Notary v2)
              notation sign \
                --signature-format cose \
                --key azure-kv://corp-keyvault/signing-key \
                $(acrName).azurecr.io/$(imageRepository):$(Build.BuildId)
            displayName: 'Sign container image'

          - script: |
              # Attach SBOM to container image
              oras attach \
                --artifact-type application/spdx+json \
                $(acrName).azurecr.io/$(imageRepository):$(Build.BuildId) \
                $(Build.BinariesDirectory)/_manifest/spdx_2.2/manifest.spdx.json
            displayName: 'Attach SBOM to image'

          - task: Docker@2
            displayName: 'Push signed image'
            inputs:
              containerRegistry: 'acr-connection'
              repository: $(imageRepository)
              command: 'push'
              tags: |
                $(Build.BuildId)

  - stage: DAST
    displayName: 'Dynamic Security Testing'
    dependsOn: ContainerSecurity
    condition: and(succeeded(), eq(variables['Build.SourceBranch'], 'refs/heads/main'))
    jobs:
      - job: ZAPScan
        displayName: 'OWASP ZAP Scan'
        steps:
          - script: |
              # Deploy to staging environment
              kubectl apply -f k8s/staging/ --namespace staging
              kubectl rollout status deployment/order-service --namespace staging --timeout=300s
            displayName: 'Deploy to staging'

          - script: |
              # Run OWASP ZAP baseline scan
              docker run --rm \
                -v $(Build.SourcesDirectory)/zap:/zap/wrk:rw \
                ghcr.io/zaproxy/zaproxy:stable \
                zap-baseline.py \
                -t https://staging-api.contoso.com \
                -J zap-report.json \
                -r zap-report.html \
                -c zap-config.conf \
                -I
            displayName: 'OWASP ZAP baseline scan'

          - publish: $(Build.SourcesDirectory)/zap
            artifact: 'DAST-Results'

Phase 3: Supply Chain Security

SLSA Provenance Generation

# .github/workflows/slsa-provenance.yml
name: SLSA Provenance
on:
  push:
    branches: [main]

permissions:
  id-token: write
  contents: read
  attestations: write

jobs:
  build-with-provenance:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v4

      - name: Build artifact
        run: |
          dotnet publish -c Release -o ./publish
          tar -czf order-service-$(date +%Y%m%d).tar.gz -C ./publish .

      - name: Generate SLSA provenance
        uses: slsa-framework/slsa-github-generator/.github/workflows/generator_generic_slsa3.yml@v2.0.0
        with:
          base64-subjects: |
            $(sha256sum order-service-*.tar.gz | base64 -w0)
          upload-assets: true

      - name: Attest build provenance
        uses: actions/attest-build-provenance@v1
        with:
          subject-path: 'order-service-*.tar.gz'

Admission Controller for Image Verification

# k8s/admission-policy.yaml
apiVersion: admissionregistration.k8s.io/v1
kind: ValidatingAdmissionPolicy
metadata:
  name: "require-signed-images"
spec:
  failurePolicy: Fail
  matchConstraints:
    resourceRules:
      - apiGroups: [""]
        apiVersions: ["v1"]
        operations: ["CREATE", "UPDATE"]
        resources: ["pods"]
    namespaceSelector:
      matchLabels:
        security-policy: "strict"
  validations:
    - expression: |
        object.spec.containers.all(c,
          c.image.startsWith('corpcontainerregistry.azurecr.io/')
        )
      message: "All container images must come from the corporate registry"
    - expression: |
        !object.spec.containers.exists(c,
          c.securityContext == null || c.securityContext.runAsNonRoot != true
        )
      message: "All containers must run as non-root"
    - expression: |
        !object.spec.containers.exists(c,
          c.securityContext == null || c.securityContext.readOnlyRootFilesystem != true
        )
      message: "All containers must use read-only root filesystem"
---
# Ratify configuration for signature verification
apiVersion: config.ratify.deislabs.io/v1beta1
kind: Verifier
metadata:
  name: notation-verifier
spec:
  name: notation
  artifactTypes: application/vnd.cncf.notary.signature
  parameters:
    verificationCertStores:
      ca:
        ca-certs:
          - corporate-signing-ca
    trustPolicyDoc:
      version: "1.0"
      trustPolicies:
        - name: "corporate-images"
          registryScopes:
            - "corpcontainerregistry.azurecr.io/**"
          signatureVerification:
            level: strict
          trustStores:
            - "ca:ca-certs"
          trustedIdentities:
            - "x509.subject: CN=Contoso Code Signing"

Phase 4: Security Findings Management

Unified Security Dashboard

public class SecurityFindingsAggregator
{
    private readonly ILogger<SecurityFindingsAggregator> _logger;

    public async Task<SecurityDashboard> AggregateFindings()
    {
        var dashboard = new SecurityDashboard();

        // Aggregate from GitHub Advanced Security
        var codeqlFindings = await _githubClient.GetCodeScanningAlertsAsync("contoso", "order-service");
        var secretAlerts = await _githubClient.GetSecretScanningAlertsAsync("contoso", "order-service");
        var dependabotAlerts = await _githubClient.GetDependabotAlertsAsync("contoso", "order-service");

        // Aggregate from container scanning
        var containerFindings = await _defenderClient.GetContainerVulnerabilitiesAsync("corpcontainerregistry");

        // Aggregate from Defender for Cloud
        var cloudFindings = await _defenderCloudClient.GetSecurityAlertsAsync();

        dashboard.Summary = new SecuritySummary
        {
            CodeVulnerabilities = codeqlFindings.Count(f => f.State == "open"),
            SecretExposures = secretAlerts.Count(f => f.State == "open"),
            DependencyVulnerabilities = dependabotAlerts.Count(f => f.State == "open"),
            ContainerVulnerabilities = containerFindings.Count(f => f.Severity >= Severity.High),
            CloudMisconfigurations = cloudFindings.Count(f => f.Status == "Active"),
            MeanTimeToRemediate = CalculateMTTR(codeqlFindings.Concat<ISecurityFinding>(dependabotAlerts)),
            SLACompliance = CalculateSLACompliance(codeqlFindings)
        };

        // Calculate risk score
        dashboard.RiskScore = CalculateRiskScore(dashboard.Summary);

        return dashboard;
    }

    private double CalculateRiskScore(SecuritySummary summary)
    {
        return 100.0
            - (summary.CodeVulnerabilities * 5)
            - (summary.SecretExposures * 20)
            - (summary.DependencyVulnerabilities * 3)
            - (summary.ContainerVulnerabilities * 8)
            - (summary.CloudMisconfigurations * 4);
    }
}

SLA for Security Findings

Best Practices

1. Shift left pragmatically: Developers need findings in their IDE/PR, not in a separate security tool
2. SBOM everything: Generate and attach SBOMs to every artifact — it's becoming a regulatory requirement
3. Sign container images: Use Notation/Notary v2 with admission controllers to prevent unsigned images
4. Secret scanning with push protection: Block commits containing secrets before they reach the repository
5. Automate dependency updates: Dependabot + auto-merge for patch updates, manual review for major
6. IaC scanning in PR: Catch Bicep/Terraform misconfigurations before they deploy
7. DAST in staging: Run OWASP ZAP against staging on every main branch build

Architecture Decision and Tradeoffs

When designing integrated solutions solutions with Azure + Power Platform, consider these key architectural trade-offs:

Recommendation: Start with the managed approach for most workloads and move to custom only when specific requirements demand it.

Validation and Versioning

• Last validated: April 2026
• Validate examples against your tenant, region, and SKU constraints before production rollout.
• Keep module, CLI, and SDK versions pinned in automation pipelines and review quarterly.

Security and Governance Considerations

• Apply least-privilege access using RBAC roles and just-in-time elevation for admin tasks.
• Store secrets in managed secret stores and avoid embedding credentials in scripts or source files.
• Enable audit logging, data protection policies, and periodic access reviews for regulated workloads.

Cost and Performance Notes

• Define budgets and alerts, then monitor usage and cost trends continuously after go-live.
• Baseline performance with synthetic and real-user checks before and after major changes.
• Scale resources with measured thresholds and revisit sizing after usage pattern changes.

Official Microsoft References

• https://learn.microsoft.com/azure/architecture/
• https://learn.microsoft.com/azure/well-architected/
• https://learn.microsoft.com/power-platform/guidance/

Public Examples from Official Sources

• These examples are sourced from official public Microsoft documentation and sample repositories.
• Documentation examples: https://learn.microsoft.com/azure/well-architected/
• Sample repositories: https://github.com/Azure/ArchitectureCenter
• Prefer adapting these examples to your tenant, subscriptions, and governance requirements before production use.

Key Takeaways

• DevSecOps requires security at every stage: code, dependencies, containers, infrastructure, and runtime
• GitHub Advanced Security provides CodeQL, secret scanning, Dependabot, and dependency review in one platform
• Azure DevOps orchestrates the security pipeline with gates that prevent insecure code from reaching production
• SBOM and SLSA provenance are essential for software supply chain security
• Container signing with admission controllers creates a trust chain from build to runtime

Further Reading

• GitHub Advanced Security
• Azure DevOps Security Scanning
• Microsoft Defender for Containers
• SLSA Framework
• Notation Container Signing
