Customer Portal: Secure External Access with Azure B2C, Power Pages, and SharePoint

Introduction

[Explain business need: enable partners/customers to access resources securely without internal AD accounts; integrated experience across identity, portal UX, and content repositories.]

Solution Architecture

flowchart TB CUSTOMER[External Users] --> B2C[Azure AD B2C] B2C --> PORTAL[Power Pages Portal] PORTAL --> DATAVERSE[(Dataverse)] PORTAL --> SPO[SharePoint Online] PORTAL --> FUNC[Azure Functions] FUNC --> STORAGE[(Azure Storage)] DATAVERSE --> POWERAUTO[Power Automate] POWERAUTO --> EMAIL[Email Notifications] SPO --> GOVERNANCE[DLP & Sensitivity Labels]

Components Overview

Component	Role	Key Features
Azure AD B2C	External identity provider	Social logins, MFA, custom policies
Power Pages	Portal framework	Low-code, responsive, integrated auth
Dataverse	Customer data store	Tables, business rules, security roles
SharePoint	Document repository	External sharing, versioning, DLP
Power Automate	Workflow automation	Approvals, notifications, integrations

Step-by-Step Guide

Step 1: Configure Azure AD B2C Tenant

# Create B2C tenant (via Azure Portal)
# Tenant name: contosocustomers.onmicrosoft.com

# Register Power Pages app
az ad app create --display-name "Customer Portal" --sign-in-audience AzureADandPersonalMicrosoftAccount

User Flows:

Sign-up and sign-in (email verification)
Password reset (self-service)
Profile editing

Custom Attributes:

Company Name
Customer Tier (Bronze, Silver, Gold)
Account Manager

Step 2: Create Power Pages Site

Via Power Platform Admin Center:

Create new Power Pages site
Select template: "Partner Portal"
Configure authentication: Azure AD B2C
- Authority: https://contosocustomers.b2clogin.com/contosocustomers.onmicrosoft.com/B2C_1_SignUpSignIn
- Client ID: from B2C app registration

Step 3: Design Portal Pages

Home Page:

<div class="hero-section">
    <h1>Welcome, {{ user.fullname }}</h1>
    <p>Your account tier: <strong>{{ user.customertier }}</strong></p>
</div>

<div class="quick-links">
    <a href="/resources">Document Library</a>
    <a href="/support">Submit Support Ticket</a>
    <a href="/profile">My Profile</a>
</div>

Document Library (Dataverse Integration):

{% entitylist id:'customer-documents' %}
{% endentitylist %}

Step 4: Dataverse Security Model

Tables:

Customer Account (extends Contact)
Support Ticket
Shared Document Metadata

Web Roles:

Customer User (read own records)
Premium Customer (read + create tickets)
Guest (browse public resources only)

Table Permissions:

Table: Support Ticket
Web Role: Customer User
Privileges: Create (own), Read (own), Write (own)
Scope: Contact (relationship to authenticated user)

Step 5: SharePoint Integration

Enable External Sharing:

Set-SPOSite -Identity https://contoso.sharepoint.com/sites/customerportal -SharingCapability ExternalUserAndGuestSharing

Embed Document Library in Portal:

<iframe src="https://contoso.sharepoint.com/sites/customerportal/_layouts/15/embed.aspx?List={listid}&View={viewid}" width="100%" height="600"></iframe>

Or via Power Automate:

Trigger: When file is added (SharePoint)
Action: Create record in Dataverse (Shared Document Metadata)
  - Title: File Name
  - URL: File Link
  - Shared With: Portal User

Step 6: Support Ticket Workflow

Power Automate Flow:

Trigger: When a row is added (Dataverse - Support Ticket)
Condition: If Severity = "High"
- Yes: Create Planner task for support team
- No: Send email to support queue
Action: Update ticket status to "In Progress"
Action: Notify customer via portal notification

Step 7: Document Approval Workflow

Trigger: When file is added to "Pending Approval" folder (SharePoint)
Action: Start approval process
  - Approvers: Account Manager (from B2C custom attribute)
Condition: If Approved
  - Action: Move file to "Approved Documents" library
  - Action: Grant access to customer via external sharing link
  - Action: Send notification to customer portal

Step 8: Multi-Factor Authentication

B2C Custom Policy (XML):

<TechnicalProfile Id="AAD-UserReadUsingObjectId">
  <Metadata>
    <Item Key="IncludeClaimResolvingInClaimsHandling">true</Item>
  </Metadata>
  <OutputClaims>
    <OutputClaim ClaimTypeReferenceId="strongAuthenticationPhoneNumber" />
  </OutputClaims>
</TechnicalProfile>

MFA Enforcement:

<OrchestrationStep Order="3" Type="ClaimsExchange">
  <ClaimsExchanges>
    <ClaimsExchange Id="PhoneVerification" TechnicalProfileReferenceId="PhoneFactor-InputOrVerify" />
  </ClaimsExchanges>
</OrchestrationStep>

Advanced Features

Custom Branding

B2C Page Customization:

<!-- custom.html hosted in Azure Storage -->
<!DOCTYPE html>
<html>
<head>
    <title>Contoso Customer Login</title>
    <link rel="stylesheet" href="custom.css">
</head>
<body>
    <div id="api"></div> <!-- B2C injects auth UI here -->
</body>
</html>

Analytics & Monitoring

Application Insights Integration:

// Power Pages tracking code
appInsights.trackPageView({ name: 'DocumentLibrary', properties: { userTier: '{{ user.customertier }}' } });

B2C Audit Logs:

AuditLogs
| where OperationName == "Sign-in activity"
| extend UserPrincipalName = tostring(TargetResources[0].userPrincipalName)
| summarize LoginCount = count() by UserPrincipalName
| order by LoginCount desc

Self-Service Profile Management

Power Pages Form:

{% editable snippets 'profile-form' type: 'html' %}
<form method="post" action="/profile/update">
    <input name="fullname" value="{{ user.fullname }}" />
    <input name="email" value="{{ user.email }}" readonly />
    <input name="companyname" value="{{ user.companyname }}" />
    <button type="submit">Update Profile</button>
</form>
{% endeditable %}

Security & Compliance

Data Loss Prevention

New-DlpCompliancePolicy -Name "Customer Portal Policy" -SharePointLocation "https://contoso.sharepoint.com/sites/customerportal"
New-DlpComplianceRule -Name "PII Protection" -Policy "Customer Portal Policy" -ContentContainsSensitiveInformation @{Name="Credit Card Number"} -BlockAccess $true

Conditional Access

B2C Conditional Access (via Azure AD Premium P2):

Require MFA for high-risk sign-ins
Block access from untrusted locations
Require compliant device for sensitive documents

Audit & Compliance Reporting

# Export B2C sign-in logs
Get-AzureADAuditSignInLogs -Filter "appId eq 'app-id'" | Export-Csv -Path "b2c-logins.csv"

# SharePoint access reports
Get-SPOSiteGroup -Site https://contoso.sharepoint.com/sites/customerportal | Select-Object Title, Users

Performance Optimization

Enable CDN for Power Pages static assets
Use SharePoint CDN for document thumbnails
Cache Dataverse queries with OutputCache in portal code
Optimize B2C token size (minimal claims)

Cost Management

Service	Cost Driver	Optimization
Azure AD B2C	MAU (Monthly Active Users)	Use free tier (50K MAU)
Power Pages	Anonymous/authenticated users	Monitor user count
SharePoint	Storage + API calls	Archive inactive docs
Power Automate	Flow runs	Consolidate triggers

Troubleshooting

Issue: Users can't sign in
Solution: Verify B2C app registration redirect URIs; check user flow assignment

Issue: SharePoint documents not visible
Solution: Verify external sharing settings; check permission inheritance

Issue: Portal performance slow
Solution: Enable Output Cache; review liquid template complexity

Best Practices

Use B2C custom policies for advanced scenarios
Implement tiered access (Bronze/Silver/Gold)
Automate user provisioning via Graph API
Monitor portal usage analytics
Test external user experience regularly

Key Takeaways

Azure AD B2C provides enterprise-grade external identity.
Power Pages accelerates portal development with low-code.
SharePoint enables secure document collaboration.
Dataverse centralizes customer data with robust security.
Power Automate orchestrates approval and notification workflows.

Next Steps

Implement multi-language support for global customers
Add AI Builder for document processing
Build mobile app experience via Power Apps
